An eco-stove built from metal waste: EcoManos

SDG(s)

Sustainable Development Goal(s)

7Affordable and clean energy

9Industry, innovation and infrastructure

10Reduced innequalities

11Sustainable cities and communities

Disclaimer:

Please be aware that the content herein is comprised of personal reflections, observations, and insights from our contributors. It is not necessarily exhaustive or authoritative, but rather reflects individual perspectives. While we aim for accuracy, we cannot guarantee the completeness or up-to-date nature of the content.

What is the name of the solution holder? (main contact person, if multiple)

Pablo Duran, Co-founder

What is the address and preferred way to contact the solution holder?

https://www.linkedin.com/in/pablodarioduran/?originalSubdomain=ar ecomanos3i@gmail.com

Does the solution holder have any institutional affiliation in country?

Pablo Durán, EcoManos, Triple Impact Social Venture, and Kalpa, Impacts Incubator

What is the purpose of the solution? (brief problem & solution description)

This solution consists of an innovative high-efficiency metal stove (rocket combustion system) of 5,000 Kcal which fuel is biomass or organic waste. Externally it has a protective mesh that may or may not have thermal mass; in addition, it vents combustion gases to the outside, making it extremely safe. To empower people and teach them how to build their own eco-stoves from metal waste, manufacturing workshops are held in low-income neighborhoods. The purpose of the eco-stove is not only to heat but also to cook and heat sanitary water. For manufacturing it, only machines and tools used for hobbies are needed, so they are easily accessible.

Please upload a picture of the solution.

Please insert a link to the solution.

https://www.facebook.com/EcoManosInnovacion

Is this solution DIY / open source or IP protected?

DIY / open source

Will the solution holder be able to train others (including end-users) in using or replicating the solution?

Yes

What is the unit cost of this Solution along with any additional cost for maintenance and training?

Is this solution a prototype or product?

Product

If this solution is a product, is it available in the market (off the shelf) or advance order has to be given?

Available in market

What is the Technological Readiness Level (TRL) of this solution?

Full commercial application

How much has this solution already been diffused? Is there potential feedback from end-users available?

Please upload a link of end-user feedback

Are there any efficiency benchmarks for this solution (eg. how much energy does it save; how much cheaper does it produce energy than current market rates/ current household expenditure / cost per kW h)?

The eco-stove consumes the organic waste that accumulates in street corners, such as pruning twigs, cardboard, dry leaves, etc. It is extremely safe, it does not generate fumes or particulates, and it vents the monoxide to the outside which prevents poisoning. Therefore, this device provides heat: SAFELY: Because combustion gases are vented to the outside, which prevents poisoning and death from carbon monoxide inhalation. EFFICIENTLY: Because it has a measured coefficient of performance of 80%, one of the highest available for homes and industries; that is, it makes much better use of fuel. ECONOMICALLY: Because it feeds on small pruning branches, wood waste from crates or scraps, pallets, chipping, leaves and dry compressed grass, etc. Also, because its construction is made with standard materials, most of which can be recovered. SUSTAINABLY: Because it works by burning dry organic waste in a very controlled way, that is, biomass that is renewable energy and very easily accessible.

Are there any other potential bottlenecks affecting cross-border or in country diffusion of this solution?

Please attach a consent form or add an official link to this solution.

Consent to share form or official link.
